Gabriel 85931 Shock Absorber

Gabriel 85931 FleetLine Shock Absorber

Upgrade Gabriel Part Number: 89458

The Gabriel 85931 FleetLine Shock Absorber delivers the durability and performance that heavy-duty truck fleets demand.  This shock is built tough, with features like a large bore for increased fluid capacity,  forged steel eye rings, and arc-welded end mounts to withstand harsh conditions. Its self-compensating piston seal ensures consistent damping for reduced fade and extended shock life. The FleetLine 85931 maximizes driver control and comfort while minimizing wear and tear on your vehicles. Choose Gabriel FleetLine for a smoother, more reliable ride.

Product Line:    FleetLine
Extended Length:    22.52 in.    572.01 mm.
Collapsed Length:    14.52 in.    368.81 mm.
Stroke:    8 in.    203.2 mm.
Bore:    1-5/8 in.
Dust Tube:    YES
Recoil Cutoff:    YES
Rebound:    1435 lb.
Compression:    220 lb.

Upper Mount Code:    ES177
Upper Mount Kit  (QTY):    Not Req'd.
Lower Mount Code:    ES161
Lower Mount Kit  (QTY):    n/a
External Diameter Illustration:    G
