Delco Remy 8200308 39MT Starter Motor

Genuine Delco Remy 39MT Starter Motor 8200308

39MT Heavy-Duty Gear Reduction Starter

•  New service models come standard with Over Crank Protection (OCP). OCP monitors the internal temperature and
prevents thermal damage to the starter by preventing over-cranking.

•  These models feature an Integral Magnetic Switch (IMS). IMS reduces voltage drop and ensures the solenoid receives the maximum available voltage in any starting condition.

•  Rotatable flange models were designed to improve service flexibility and part number consolidation. They easily replace competitive units and provide full industry application coverage.

•  Warranty for All Makes models: 3 year/unlimited miles (Applicable to U.S. and Canada only)

Diameter:  4.50 in
Pitch:  0.80 mm
Pinion Pitch:  0.75 mm
Mounting Flange to End of Case:  357.90 mm
Mounting Flange to Pinion End at Rest:  46.70 mm

Model:  39MT
Rotation Direction:  Clockwise
Bolt Hole Quantity:  3
Tooth Quantity:  11
Polarity:  Insulated
Pinion Gear Tooth Quantity:  11
Over Crank Protection:  Yes
Solenoid Position:  082
Family:  39MT
Solenoid Position Angle:  82 deg
Nose Cone Material:  Aluminum
Re-Clockable Flange:  Yes
Solenoid Attached:  Yes
Nose Cone Type:  Open Nose

Mounting Type:  SAE 3
Housing Material:  Steel

Voltage:  12 V
System Voltage:  12 V
Nominal Output:  12 Volts peak at 7.3 kW/24 Volts peak at 9.0 kW

Power Rating:  7.30 kW

Parts Cross Reference

Genuine Freightliner Truck Parts Warranty

With limited warranty protection on aftermarket truck parts sold through authorized Freightliner dealers, DTNA covers defective materials and/or workmanship for one year. For details on coverage, contact your local dealer.
